Additional functions: cutting, rust removal and cleaning 4 in 1. And welding is the main function.
Features
Low consumables, long lifespan, stable technology, and lifetime after-sales service.
Expandable
It can be configured with a robotic arm or CNC welding machine, and standard handheld heads can be replaced to meet various welding needs.
Cost Savings
Welding is 3-10 times faster than traditional methods, eliminating the need for 3-5 welders per machine. It requires no specialized skills, with mastery possible in half a day. The automatic wire feed ensures smooth, even welds, while reducing manual effort and post-weld grinding.
Minimal Hot Zone Impact
Laser welding has a concentrated hot zone, resulting in zero workpiece deformation, scar-free welds, and strong welds.
Environmentally Friendly and Safe
Traditional welding machines generate significant environmental and worker health hazards due to flying dust and harmful gases. Laser welding machines pose almost no environmental risk.
A full set of professional welding nozzles
Meets the needs of tailored welding, fillet welding, lap welding, and other welding processes.
| Cooling system | Rated Power | Rated Voltage | Shielding gas | Weld penetration | Size(mm) | Net(KG) |
|---|---|---|---|---|---|---|
| Water-cooled | 1500 W | 220V AC | Nitrogen or argon | 0.4-3.5mm | 400*720*920mm | 110 |
| Water-cooled | 2000 W | 220V AC | Nitrogen or argon | 0.4-4.5mm | 400*720*920mm | 110 |
| Water-cooled | 3000 W | 380V AC | Nitrogen or argon | 0.4-5.5mm | 525*1050*1200mm | 150 |
| Cooling System | Length of fiber Opiic Cable | Laser wavelength | Protective gas | Welding speed |
|---|---|---|---|---|
| Water-cooled | 10 m | 1070+5NM | Nitrogen, Argon | 0.7-2.0 m/minute |
| Rated Frequency | Wire diameter | Welding seamrequirement | Overall Dimension | Weight |
|---|---|---|---|---|
| 50 HZ | 0.8 / 1.0 / 1.2 / 1.6 | Maximum 2mm | 480x680x920mm | 120 Kg |
| Handheld laser welding machine | Specification | Quantity(Set) |
|---|---|---|
| Laser Generator | 1500W/2000W/3000W | 1 |
| Handheld welding gun | Single swing welding gun | 1 |
| Transmission fiber optic | 10m | 1 |
| Water chiller | 1500W/2000W/3000W | 1 |
| Automatic wire feeder | custom-made | 1 |
| Main control board | XL V1.0 | 1 |
| Laser protective lenses | 18×2 or custom-made | 6 |
| Laser copper nozzle | custom-made | 6 |
| Wire feeding tube | 4m | 1 |
| Model | 1500 W | 2000 W | 3000 W |
|---|---|---|---|
| Rated Power | 4.5 KW | 6 KW | ≤ 8 KW |
| Rated Voltage | 220 V | 220 V | 380 V |
| Thickness | 0.2 mm | 0.2 mm | 0.2 mm |
| Maximum penetration thickness | 3.5 mm | 4.5 mm | ≤ 6 mm |
Product Details
Handheld Welding Torch
Control System
Sheet metal
Wire feeder core motor
High speed without Catton, Stable operation and long-term work without fever.
Wire feed wheel standard
Low density aluminum alloy suitable for U whee, Stainless steel high strength applicable V wheel.
Simple operation oflaser welding machine
Complex operation oftraditional welding machine
Welding speed of 2 meters/minute
Inefficient traditional welder
High Welding Strength
Enhanced Efficiency
Welding Process
Beautiful welding effect
Coarse Weld
Uneven weld bead finish
Laser welding machine lessharmful
Just wear goggles
Traditional weldingmachine heat huge
